Chapter 11 – General I/O Functions
A
A
i
i
U
U
I
I
n
n
t
t
3
3
2
2
r
r
a
a
t
t
e
e
ASP Sampling rate in 0.5 msec steps (5 .. 2000), Example:
Value
Time
Sampling Frequency
1
0,5 ms
2000 Hz * (* for internal test only)
2
1 ms
1000 Hz *
3
1.5 ms
666 Hz *
4
2 ms
500 Hz *
5
2.5 ms
400 Hz
10
5 ms
200 Hz
20
10 ms
100 Hz
100
50 ms
20 Hz
200
100 ms
10 Hz
1000
500 ms
2 Hz
2000
1000 ms
1 Hz
