Aim MXL2 - Page 13

RPM
13
MXL2
Point 1: low voltage of the coil
Point 2: connected to the spark plug
Point 3: connected to the +12V of the battery
After connecting the RPM signal, please use the software Race Studio 3 for enabling
the RPM channel.
