Aim MXL2 - Page 58

58
CHAPTER 16
- Display
- Backlight
- Ambient light sensor
- Alarm LEDs
- Shift Lights
- CAN connections
- ECU connections
- External modules connection
- Connectors
- Analog inputs
- Digital inputs
- Digital outputs
- Inertial platform
- WiFi connection
- Internal memory
- Body
- Pushbuttons
- Dimensions
- Weight
- Power consumption
- Waterproof
LCD Display+graphical portion
White or red
Yes
6 RGB freely configurable
10 integrated freely co
nfigurable RGB LEDs
3
CAN, RS232, K-Line
GPS Module, Channel Expansion, Lambda controller,
SmartyCam HD
2 motorsport connectors
8 fully configurable, max frequency 1 KHz each.
4 speed inputs, LAP signal, coil RPM input
2 up to 1 Amp each
Internal 3 axis +/-5G accelerometer + 3 axis gyro
Yes
4 Gb
Anodized aluminium
Metallic
187,8x103x21 mm
530g
400 mA
IP65
187.81.2
1.2
103
149.9
66.4
21
15.916
2.5
