- 15 -
Mounting positions and image view area3-3
When using the camera module, if the rain hood is attached a portion of it will show up in the camera display.
(with mounting position of 1350 mm (4'4"))
Zoom picture
Up/Down
Left/Right
Objects appear smaller due to greater distortion in the surrounding sections compared to
the central section, but a wider area is displayed.
The display range is a rough estimation and may change due to the installation environ-
ment.
The zoom position can be changed.
At the time of shipment, the zoom position is set at "Zoom central".
Zoom <Left> Zoom <Center> Zoom <Right>
Approx.
1300 mm
(4'3")
Approx. 100 mm (4")
Approx. 900 mm (3')
Approx. 100 mm (4")
Approx.
1300 mm (4'3")
Approx. 900 mm (3')
Approx.
1050 mm
(3' 5")
Approx. 700 mm
(2' 3")
Zoom <Up> Zoom <Center> Zoom <Down>
Approx. 850 mm (2'9")
1350 mm (4'4") 1350 mm (4'4") 1350 mm (4'4")
Approx. 700 mm (2'3")
Approx. 850 mm (2'9")
Camera
center
Camera
center
Camera
center
Approx. 2050 mm
(6' 9")
Approx. 1650 mm
(5' 5")
Approx. 1400 mm
(4' 7")
Approx. 1200 mm
(4')
Approx. 950 mm
(3' 1")
Approx. 550 mm
(1' 9")
Wide picture
Up/Down
Left/Right
An area over a range of approx. 170° in a 500 mm radius from the camera displays.
(The display range is a rough estimation and may change due to the installation environ-
ment.)
Mounting position 1350 mm (4' 4")
Approx. 1050 mm (3'5")
1350 mm (4'4")
500 mm (20")
500 mm (20")
500 mm (20")
500 mm
(20")
500 mm (20")
500 mm (20")
500 mm (20") 500 mm (20")
500 mm (20")
1550 mm (5'1")
Approx. 1050 mm (3'5")
Approx. 170°
C
amera center
Camera center
Approx. 1800 mm
(5' 11")
Approx. 2000 mm
(6' 7")
Approx. 750 mm
(2' 5")
Approx. 950 mm
(3' 2")
Mounting position 1550 mm (5' 1")
