Common area
Residence trunks
* See page 4 for various types.
Power supply
Sub trunk line 1A
Common trunk line 2
Residence trunks
Sub trunk line 1B
Common trunk line 1
Residence trunks
Sub trunk line 2A
Common trunk line 1
Residence trunks
Sub trunk
line 2B
Common trunk line 2
Audio signal line (1)
Video signal line (1)
Power supply line (1)
Expanded video bus control unit
GT-VBX
Expanded bus control unit
GT-BCX
Video bus control unit
GT-VBC
Bus control unit
GT-BC
Bus control unit
GT-BC
Entrance station
Security guard station
GT-MK
Capacity
Entrance station Maximum 16 stations (up to 8 sta-
tions per trunk)
Residential stations per sub trunk
line
Maximum 125 stations (up to 25 sta-
tions per trunk)
Security guard station Maximum 4 stations
Residential station Maximum 500 stations
Residential stations in the same resi-
dence (other than GT-2C)
Maximum 4 stations (2 monitor sta-
tions)
Bus control units per common trunk line
Maximum 1 unit
Bus
control units per sub trunk line Maximum 1 unit
Master stations in the same residence
(GT-2C)
Maximum station
Sub master monitor station Maximum 3 stations
Expanded system configuration diagram1-2
The wiring of the sub trunk line is the same as the standard system.
To Next Page
