Airsight XX59A - PTZ and Cruise Controls

23
Figure 4.5
Set Preset: It supports 9 preset positions. First, control the camera to rotate to the special position you need
to set, click Set Preset button
it will pop-up a dialog frame (Figure 4.5), choose any number (1-9).
Call Preset: It supports 9 preset positions. If you want to monitor an important area quickly and precisely,
just click Call Preset Position button
it will pop-up a dialog frame (Figure 4.5), choose the number, then
camera will rotate to the preset position automatically.
If you want to use Call Preset, you have to Set Preset first.
NOTE: If you set different positions with a same number, camera will record the last position setting only.
Cruise: Preset cruise, camera can cruise according to the different presets you set.
Click this icon, the camera will rotate up and down, i.e., vertical tilt, click to stop it.
Click this icon, the camera will rotate left and right, i.e., horizontal pan, click to stop it.
Click this icon, IO output Switch ON. Click to set it OFF.
Fig
ure 4.6
PTZ speed: set value from 1 to 100, click the icon to go back to the factory settings.
Brightness: set value from 0 to 255, click the icon to go back to the factory settings.
Contrast: set value from 0 to 255, click the icon to go back to the factory settings.
Hue: set value from -128 to 127, click the icon to go back to the factory settings.
Saturation: set value from 0 to 200, click the icon, it will back to factory settings.
