AJAX AJ16 User Manual

5.2 Dentist Unit
Handpiece Activation
The handpieces automatically activate when you lift a handpiece
from its holder or pull the Continental whip forward. Press the foot
control to operate the activated handpiece.
5.2.1 Flexible Arm Brake
The flexible arm brake allows you to place varying amounts of
weight (2.5kg. maximum) on the control head tray while maintaining
the position. The thumb-actuated brake restricts vertical movement
but allows for side-to-side horizontal positioning of the control head
(see Figure 21.-22.).
21
Figure 22 New Hanging
Type Dentist Unit
Figure 21 Luxury Whip
Arm Dentist Unit
A：Luxury Whip Arm Dentist Unit : Switch of the Brake
B： New Hanging Type Dentist Unit: Switch of the Brake
P/N: 8013093 Rev：F
AJ16 User's Guide
