AJAX AJ16 User Manual

24
Assistant’s Unit include the control panel, Strong Suction, Weak Suction ,
3-ways syringe, and the solid collector in the Water Unit, The solids
collector (refer to Figure 26) connects with Strong/Weak suction handle
to separate solids from the evacuated material.
5.4 Assistant's Unit
Figure 26 AJ16 Assistant's Unit
A Weak Suction solid collector
B Strong Suction solid collector
A
B
Rotatable Water Unit
If your Dental Unit is AJ126,Water Unit can swivel outward 60 °, it is
convenient to the operation .Figure 25 .
Figure25 AJ 16
rotatable water unit
P/N: 8013093 修订版本：F
AJ16 User's Guide
P/N: 8013093 Rev：F
