3 Product Specification
Power dissipation
AC220V
,50/60Hz,350V
A
Illuminance of dental light
8000-20000 Lux
Intensity of X-ray viewer
≥2000cd/m
2
Carrying capacity of
dental chair
1323N (135kg)
Carrying capacity of
Dentist Unit tray
2.5kg
High-speed air turbine
handpiece
Idling speed≥35x10
3
r/min
(Air pressure:0.22Mpa)
Low-speed air motor
handpiece
Idling speed≥18x10
3
r/min
(Air pressure:0.3Mpa)
The highest position of the
patient chair from the
ground
830mm
The lowest position of the
patient chair from the
ground
380mm
Backrest movement range
107
°
- 177
°
Headrest extension range
0-150mm
Ambient temperature
5
℃
～
40
℃
Air supply pressure
0.55-0.80Mpa
W
ater supply pressure
0.2-0.4Mpa
Main Line Fuse
250V 6A
Power cord
227 IEC(R
VV)3x0.75mm
5
P/N: 8013093 Rev
：
F
AJ16 Use
r's Guide
T
able1. Product Specification
7
9
Table of Contents
Default Chapter
2
Table of Contents
2
1 Safety Information
4
2 Wa R M I N G
6
3 Product Introduction
8
4 Introduction
9
About Your AJ16 Dental Unit
9
Product Introduction
10
AJ16 P3 Dental Unit
10
AJ16 P2 Dental Unit
11
AJ16 P1 Dental Unit
12
Structure
17
The Model of Hydraulic
17
The Hydraulic System
18
5 Basic Operation
19
Dental Chair
19
Power
19
Floor Unit Fuse Configuration
20
The Rotation of Chair
21
Foot Switch
22
Backrest of the Dental Chair
22
Headrest of the Dental Chair
23
Dentist Unit
24
Flexible Arm Brake
24
M a I N C O N T R O L P a N E
25
Foot Control
25
Water Unit
26
Assistant's Unit
27
Cuspidor
28
6 Control Panel&Setup
28
Control Panel
28
S y S T E M S T a T U
29
Chair Position
30
The Explanation of Chair Position
31
Water Heater of Water Unit
32
Program
33
Program Your Chair
33
Dental Chair Initial Settings Specification
34
Cuspidor Program
35
7 Adjustment
36
Dentist Unit
36
Handpiece Adjustment
36
3-Ways Syringe Adjustment
39
Cuspidor
39
Bowl Rinsing and Cup Filling Flow Adjustments
39
8 Clean and Asepsis
40
Handpiece Tubing Clean and Care
40
Clean the Suction Head
40
Clean the Oil Collector
41
Clean the Filter
41
Clean the Cuspidor
42
Gravity Drain Cleaning
42
Clean the Dental Light
43
Clean Dental Unit Surface
43
Appendix 2: AJ16 Electrical Wiring Diagram of Hydraulic
46
EMC Declaration of Dental Chair
48
Explanation of Symbols
52
