23
AJ16 Water Supply System
5.3 Water Unit
The self-contained water bottle supplies water to handpieces, 3-
ways syringes, and The system includes a 600ml, quick- disconnect
water bottle that mounts to the frame in the Water Unit and offers
you can easy way to switch the water source of your treatment
water (refer to figure 24)
Figure 24 AJ16 Water Supply System
Switch for pure
water bottle
Water bottle Disinfecting
water bottle
Switch for Disinfection
water Bottle
• Generally, handpiece device water supply is city water. If you
need to use the water bottle water, you should open the icon
switch as figure24.
• Before disinfection, the sterilization bottle must fill with
disinfectant. And then open the disinfecting water source switch.
P/N: 8013093 Rev：F
AJ16 User's Guide
