Wet/Dry Toggle
Chip Blow
Foot Control
Cup Filling and
Bowl Rinsing
R Button
Automatically positions chair
for entry/exit
Foot Switch
22
5.2.3 Foot Control
• To turn the water OFF, please move the Toggle to the direction as
showed in in the Figure 23.
• To turn the water ON, please move the Toggle the reverse direction.
Figure 23. Ajax Multi-Function Foot Control
5.2.2 Main Control Panel
AJ16 control panel combines chair, cuspidor , Dental Light, X-ray film
viewer control function into one touch surface. For complete
instructions on control panel operation, refer to “Control panel” on
page 25.
P/N: 8013093 Rev：F
AJ16 User's Guide
