Page 32 of 68
RN2 8 10K
resistors
Install RN2 in the indicated place. Make sure that
pin 1 of RN2, marked by the dot, goes into the
square pad in the RN2 hole pattern on the PCB.
Solder the two end pins first to make sure that RN2
is sitting level on the board. Once RN2 is level,
r the balance of the pins.
Install the Ferrite Beads
FB1 and FB2 install just like resistors. A ferrite bead is used to confine and contain the
radio frequencies generated incidentally to the operation of the controller.
Designation Value Description Done
