You can identify the resistors by color code. I always like to cross-check the
identification by using a Digital Ohm Meter.
All of the resistors can be bent at 0.45” width for easy installation.
Designation Value Color Code Done
Red, yellow, white, gold, brown
Brown, black, black, red, brown
Brown, black, black, orange, brown
Brown, black, black, orange, brown
Brown, black, black, orange, brown
Brown, black, black, orange, brown
Red, black, black, brown, brown
Red, black, black, brown, brown
Red, black, black, brown, brown
Red, black, black, brown, brown
Red, black, black, brown, brown
Red, black, black, brown, brown
Yellow, white, white, black, brown
Yellow, white, white, black, brown
Yellow, white, white, black, brown
Yellow, white, white, black, brown
Brown, green, black, brown, brown
Brown, green, black, brown, brown
Brown, green, black, brown, brown
Red, red, black, red, brown
Red, red, black, red, brown
Yellow, black, red, brown, brown
Yellow, black, red, brown, brown
Install the Diodes and Low Profile Capacitors
Bend leads to 0.45” spacing if you have a lead-bending jig.
Match the banded end of the diode to the ba
Designation Value Description Done
