AkitikA PR-101NR - Install the Bypass Capacitors; Install the Integrated Circuit Sockets; Figure 30-Align Socket Feature with Silk Screen

Page 44 of 68
D11
1N4148
75 V switching diode
D12
1N4148
75 V switching diode
Install the Bypass Capacitors
The bypass capacitors are pre-formed to the correct span. Drop each one in, and bend the
leads to around a 45 degree angle to hold the capacitors. Solder, then clip the leads in the
normal fashion.
Designation Value Description Done

C2
0.1 µF
100 volt ceramic capacitor, marked 104
C4
0.1 µF
100 volt ceramic capacitor, marked 104
C5
0.1 µF
100 volt ceramic capacitor, marked 104
C20
0.1 µF
100 volt ceramic cap
acitor, marked 104
C21
0.1 µF
100 volt ceramic capacitor, marked 104
C22
0.1 µF
100 volt ceramic capacitor, marked 104
C23
0.1 µF
100 volt ceramic capacitor, marked 104
C24
0.1 µF
100 volt ceramic capacitor, marked 104
C25
0.1 µF
100 volt ce
ramic capacitor, marked 104
Install the Integrated Circuit Sockets
Figure 30-Align socket feature with silk screen
We’ve supplied IC sockets for the op-amps that have gold-plated pins. You’ll install the
IC sockets now. The actual ICs will be installed in a later step.
Designation Watch IC socket orientation! See Figure 30 Done

U2
Solder an 8 pin IC socket in place
U3
Solder an 8 pin IC socket in place
U4
Solder an 8 pin IC socket in place
