AkitikA PR-101NR - Figure 39-Motor POT Wiring Detail

Page 59 of 68
Designation
Length D
Done

POT1 Long Wire
5/8”
Solder one end in the
upper motor terminal.
POT1 Short Wire
½”
Solder
one end in the lower motor terminal.
Figure 39-Motor POT wiring detail
Repeat the process for POT2.
Designation
Length D
Done

POT2 Long Wire
5/8”
Solder one end in the upper motor terminal.
POT2 Short Wire
½”
Solder one
end in the lower motor terminal.
Install and solder both motor POTS on the board. Guide the motor pot wires into the
labeled holes:
 Long wire into MOTOR-
 Short wire into MOTOR+
You’ll solder in 10 places for each motor POT:
 3 terminals for the right channel
 3 terminals for the left channel
 Motor+ wire
 Motor- wire
 2 mounting terminals near the center of the motor POT footprint.
Make sure that the motor wires don’t touch the metal back
-
plate of the motor
-
pot.
Perform the following 4 steps to avoid losing the nuts that will be used to attach the
volume, balance, bass and treble controls to the front panel.
Designation
Done

Pot 1 shaft Slip larger diameter washer over the shaft. Loosely
spin on a larger diameter nut.
Pot 2 shaft Slip larger diameter washer over the shaft. Loosely
spin on a larger diameter nut.
Pot 3 shaft Slip smaller diameter washer over the shaft. Loosely
spin on a smaller diameter nut.
Pot 4 shaft Slip smaller diameter washer over the shaft. Loosely
spin on a smaller diameter nut
.
