Akuvox SP-R50P User Manual

69
should be feedback from LDAP server.
 Display Name: To configure display name on Phone UI
when there is any searching result from LDAP server.
 Max Hits: To configure the maximum size of result
response from LDAP server.
 Search Delay Time: To configure delay time before
initiate LDAP searching request after you input a value
from Phone UI.
Note: For setting details, please consult with your system
administrator or Akuvox technical support team for further
information.
5.21.Phone Book->BroadSoft
Path: Web UI->PhoneBook->Broadsoft
Sections Description
Broadsoft PhoneBook To display and configure Broadsoft PhoneBook settings.
 PhoneBook Item: To select specific item to configure.
Display Name: The name displayed at IP phone’s LCD
screen when accessed via Phone UI.
 Server Address: Broadsoft PhoneBook server’s address.
 Server Port: Broadsoft PhoneBook server’s port.

Akuvox SP-R50P Specifications

General

Brand	Akuvox
Model	SP-R50P
Category	IP Phone
Language	English
