14
STABILISER AND COUPLING DEVICES
Your caravan will be tted with either an AKS 3004 stabiliser
or an AK160/300 coupling head.
SAFETY PRECAUTIONS
Always ensure that the coupling head is properly connected
to the tow vehicle’s towball every time you couple up. If this
procedure is not carried out correctly, the caravan/ trailer
may become detached from the towing vehicle! Maximum
possible articulation of the coupling head must not exceed
±25° vertically and ±20° horizontally - see Fig 14.
If exceeded, components will be overloaded and the
operation of the assembly adversely affected!
Fig 14 Maximum Articulation Of Coupling Head
25°25°
25°
25°
