34
EURO-OVERRUN DEVICES FITTED WITH
AKS 3004 STABILISER
Fully retract Jockey Wheel inner tube so that it locks against
Jockey Wheel outer tube.
Slacken Jockey Wheel Clamp handle and raise complete
assembly through cutout in body to its highest position
(ensure it doesn’t come into contact with the brake rod
assembly), fully tighten Jockey Wheel Clamp handle to
ensure the Jockey Wheel is rmly held in position.
EURO HANDBRAKE
Ensure the handbrake is fully applied to ensure that the
wheel brakes will be automatically re-applied should the
vehicle start to roll backwards.
CAUTION
If the handbrake is not fully applied as detailed above,
there is a danger that the caravan could roll backwards.
TO RELEASE
Press the handbrake down until it is parallel with the fairing
cover to ensure that the brake is correctly disengaged.
OVERRUN DEVICES
Fig 41 Handbrake lever operation
HANDBRAKE OFF HANDBRAKE ON
