17
SAFETY WARNINGS
1. In accordance with EC Directive 94/20, couplings of type
A 50-1 cannot be used (see Fig 17), your warranty will be
invalid if this type of towball is used.
2. For UK use, use the extended neck towball (type A50-X).
3. A bolted-in type ball coupling (Fig 18) is only permissible
if the thread is locked or welded.
4. The AKS 3004 cannot be used with a laterally attached
reversing lever, on the left side, when facing the
direction of trafc.
5. The towball must be free from grease, paint and other
residue, otherwise the stabilising effect is greatly reduced.
6. If friction pads become contaminated with grease, they
should be replaced.
7. The AKS 3004 should only be operated by one person,
when opening or closing the handle, to reduce injury risks.
Fig 17 A 50-1 Couplings
Fig 16 Max suitable rotation of overrun device is 25°
Fig 18 Bolted In Coupling
25°
Min.
60mm
OPERATING INSTRUCTIONS
FOR AKS 3004 STABILISER
