AL-KO CARAVAN CHASSIS - Spare Wheel Carriers

43
Caravan Make _____________________________________________ Caravan Model ____________________________________________ Year of Manufacture ________________________________________ Tyre Size (eg R195 13) ______________________________________ Dimension (X) in mm (taken from the following diagram) ___________
Hole Cluster for Spare Wheel Carrier
275
ca. 700
X
RECORD YOUR SPARE WHEEL CARRIER INFORMATION HERE
ACCESSORIES
SPARE WHEEL CARRIERS
Each caravan has a set of punched holes in the chassis
member to facilitate the tting of a spare wheel carrier. The
assembly is of a strong, lightweight construction and zinc
plated for all-weather protection. There are 3 variants to suit
most AL-KO chassis (record your tyre size on this booklet
for future reference). The carriers can be tted for left or
right hand operation and are easy to t. The telescopic frame
tubes should be lubricated periodically.
