77/91
Programmable keys.
Universal Serial Bus (USB-a) connector.
This connector is used for:
• Connect a USB headset.
• Connect an add-on module.
•
*To know the supported dongle, please refer to the Alcatel-Lucent Enterprise website or
contact your administrator.
7.2.1 install the add-on to the desk phone
1- Insert the add-on USB-A connector into the USB-A socket of the desk phone.
2- Use the add-on support to fix it to the desk phone using the provided screw.
3- The add-on is powered by the desk phone if the desk phone is connected to an
external power adapter.
If your desk phone is powered via PoE, we recommend connecting the EM200 to an
USB-C power adapter (DC 5V/2A output, not provided with the add-on).
4- Restart the desk phone (unplug and plug in the power jack if you are using an external
power adapter or the Ethernet connector – LAN).
7.2.2 Install more than one add-on module
It is possible to connect up to three similar add-on modules. It is not possible to connect EM20
and EM200 add-ons together.
Depending on how the desk phone is powered, you need to use an external power adapter
(DC 5V/2A output, not provided with the add-on) connected to the add-on.
Your desk phone is powered via PoE:
• You can connect up to three EM20. The first EM20 which is connected to desk phone must
be connected to an external power adapter.
• You can connect up to three EM200. The first EM200 which is connected to desk
phone must be connected to an external power adapter.
