Your desk phone is powered via an external power adapter:
• You can connect to one EM20 without an external power adapter.
• You can connect to one EM200 without an external power adapter.
• You can connect to two or three EM20. The first EM20 which is connected to desk
phone must be connected to an external power adapter.
• You can connect to two or three EM200. The first EM200 which is connected to
desk phone must be connected to an external power adapter.
To attach another add-on, affix and connect the new add-on to the one that is already
connected:
• The first add-on is connected to the desk phone.
• Insert the new add-on USB-A connector into the USB socket of the installed add-on.
• Use the add-on support to fix it to the add-on using the screw provided.
• Restart the desk phone (unplug and plug in the power jack if you are using an
external power adapter or the Ethernet connector – LAN).
7.2.3 Changing or updating the paper label
• Remove the protective cover (1): insert a thin object (or your fingernail) in the slot (a)
to lift the protective cover. Slide the cover down. The cover is held in place by small
notches, take care not to break the plastic cover near the notches.
Remove the cover from the other notches (c, d) by moving the cover gently from right to left.
• Remove the paper label with a thin object.
• Replace the paper label and protective cover (2):
the cover or the paper can only be placed in the right way. Insert the paper label
under the first notches (a). Then, insert the other notches by sliding the paper up (b, c,
d). If necessary, you can gently press the paper near the notch to help it to slide under
the notch.
• Put the protective cover back in the same way.
Paper label and paper label cover can be ordered separately.
