3.1.3 Upper Panel
The following figure shows the aspect of the upper panel:
Fig. 5: Upper panel
The upper casing elements are as follows:
Upper casing elements table
Items Description
A, B, C, D Screws that allow you to disassemble the router’s upper casing.
3.2 Assembly
3.2.1 Installing a DIN rail mount accessory
The device packaging includes a DIN rail mount kit to which the device can be connected to (allowing for several po-
sitions).
The kit contains 2 screws to adjust the rail mount to the underside of the device. There are a set of holes on the un-
derside that allow you to place the DIN rail mount in two different positions:
3 Components and Power Supply Alcatel-Lucent Enterprise
8 OA5725R Router
