The OA5725R router incorporates independent modules for the Wireless WAN interface. You can pick modules from
different manufacturers or choose several modules from the same provider, depending in the technology used. Gen-
erally, the firmware is independent from the device’s software. There is an UPGRADE file for each Wireless LAN
module. Please ask you distributor for the correct UPGRADE file (according to the module in your device). The
manual describing the Cellular Interface (ALU-Dm781-I) explains how to upgrade the module.
A.3 Connecting to the router
There are two ways of accessing the device CLI:
• Through the CONF connector
• Through the Telnet protocol
A.3.1 Connecting through the local console (CONF connector)
The OA5725R routers have a DB-9 female connector on the front panel known as “ CONF.”, which provides access
to the device local console. In order to configure this, you must connect the “ CONF.” port to an asynchronous termin-
al (or to a PC with terminal emulation).
Note
Configuration for the terminal must be as follows:
- Speed: 9600bps.
- Eight data bits.
- One stop bit.
- No parity bit.
- No type of flow control.
Connection to the configuration port can be done by joining a DB9 male connector cable to a DB9 female connector.
If the terminal has DB25 connectors, you will need to use an additional adapter.
Fig. 20: Connecting for configuration
A.3.2 Connection through an IP terminal (LAN 1...6 connectors)
The OA5725R router includes a default configuration that activates if you haven’t configured anything previously.
The router’s default configuration establishes the following IP address and access mask:
• IP address: 192.168.1.1
• IP mask: 255.255.255.0
Alcatel-Lucent Enterprise
Technical Information
OA5725R Router 27
