Page #104 background image
Static 1. Connect the power supply.
2. Before initialization phase 5 starts, press i, then the # key.
The Main menu appears.
3. From the Main menu, choose IP Parameters.
The IP Parameters menu appears.
4. Choose Static and press the OK key.
5. Enter the following:
a. IP address
b. Subnetwork mask
c. Router address
d. TFTP server address
e. TFTP port (69)
f. CPU address
6. Enter the required VLAN details, as follows:
a. If required, select Use VLAN and then enter the VLAN ID number.
b. Ensure that Strict VLAN is set as required. It is selected by default; de-
selecting it allows you to use a DHCP server in another VLAN.
7. Save the above parameter values by pressing the # key.
8. Exit the Main menu by pressing the * key.
The set restarts from phase 1 with the new parameters.
Note:
If an error message appears during initialization, disconnect the power adapter, then plug it in
again, so that the system restarts initialization.
4.7.1.2.3.4 Restarting initialization
If you want to change a parameter value, restart initialization, as detailed below.
To restart initialization:
1. Disconnect the IP Touch set from the power supply.
2. Reconnect the power supply.
3. Execute the initialization procedure as detailed in Table 2
4.7.1.2.4 Programming keys
This section describes how to program the programmable keys.
In fact, only the direct call key can be programmed (with a telephone number), which by default is the
sixth programmable key. However, the Personal/Dial by name key can be programmed in a similar way.
To program a key:
1. Press the i key followed by the required programmable key.
2. Press one key of the 2-way navigator (up or down).
3. Enter the telephone number to be associated with this programmable key.
4. Press OK. The set then goes back to its default display.
4.7.1.2.5 Relocating and retaining IP Touch sets
This section describes how to relocate and retain the same set.
In the procedure below, it is assumed that:
there is one DHCP server
Chapter
4
Installation and Cabling
3EH21123USAA - Ed. 01 - April 2017 - Installation Manual 104/207
