Alcatel-Lucent OXO Connect Small - IP Configuration

6.1.4 IP configuration
Tue Feb 28 2013
Please select :
IP@CPU
IP@MSK
IP@Rtr
VoIP@
Tue Feb 28 2013
Please select :
VLAN
OSDHCP
DHCP
NEXT
Scroll
down
Scroll up
This screen makes it possible to enter system IP addresses. The following softkeys are available:
• IP@CPU: IP address of the main CPU
• IP@Rtr: default IP address of the router
• IP@Msk: IP address of the sub-system mask
• VoIP@: VoIP master IP address (VoIPm).
• VLAN: Configuration of the VLAN
• DHCP: See Configuration of the OXO Connect DHCP server for IP devices on page 172
• OSDHCP: See Configuration of the OXO Connect DHCP server for Alcatel-Lucent OmniSwitch on
page 174
• NEXT: Go to the next menu
Other fixed keys of the set:
• Back: Return to the previous menu (Installation number on page 170)
• Exit: return to home page
Chapter
6
Start-Up
3EH21123USAA - Ed. 01 - April 2017 - Installation Manual 171/207
