INSTALLATION & OPERATIONS GUIDE | MICROSET 4
© Honeywell LT-MS4IOG Rev. 04 | Revised October 2015
46
BACnet object and property reference
This section shows the BACnet objects available in the MS/TP Microset 4. The tables that follow list
individual points and give details about the properties of each object listed.
Microset 4 objects
OBJECT
(INSTANCE
RANGE)
REMARKS
AI-(0) AI-0 is the Microset 4 internal temperature sensor analog input object.
AV-(90–107) RESERVED AVs for Alerton legacy Microset behavior.
AV-(0-47) General use AVs.
BV-(0-47) General use BVs. BV-40 supports the priority-array property.
BV-40 is typically used by Alerton DDC applications to receive scheduled occupancy
commands from a global controller. The priority array allows a BACnet user to override the
occupancy command. When in Occupancy mode with an internal schedule enabled, internal
schedule commands are written to BV-40 priority 16, therefore DDC applications that use BV-
40 can easily use either internal or external scheduling.
BV-(99) Disable unoccupied setpoint deadband
File (254) Provides information about the ROC file.
