4.4 Sensors and indicators 4 Design and function
4.4 Sensors and indicators
The separator is equipped with a speed sensor.
As options, an unbalance sensor and an
interlocking kit can be fitted.
Speed sensor (optional)
A speed sensor (3) indicates the speed of the
separator. The correct speed is needed to
achieve the best separating results and for
reasons of safety. Refer to type plate for speed
particulars.
Monitoring kit (optional)
For indication of any abnormal unbalance,
the separator can be equipped with a sensor
(2) monitoring the radial position of the bowl
spindle.
Cover interlocking kit (optional)
When the cover is closed the interlocking circuit
in the control system is closed (1) which makes
it possible to start the separator.
1
2
3
G08734F1
1. Cover interlocking switch
2. Unbalance s ensor
3. Speed sensor
26
