15.Connect the speaker cable to the system board.
16.Connect the right-fan cable to the system board.
17. Lift the corner of the Mylar covering the system board.
18.Adhere the power-adapter port-cable to the Mylar.
19.Connect the power-adapter port-cable to the system board.
20.Connect the Alien head LED-cable to the system board.
21. Adhere the display cable to the system board.
22.Connect the display cable to the system board and close the latch to secure the cable.
23.Adhere the tape that secures the display-cable connector latch to the system board.
24.Place the Type-C bracket on the system board and align the screw holes on the bracket to the screw holes on the system board.
25.Replace the two screws (M2x4) that secure the Type-C bracket to the system board.
Next steps
1. Install the
battery.
2. Install the rear-I/O cover.
3. Install the
wireless card.
4. Install the 2230 solid-state drive or 2280 solid-state drive in slot one, whichever applicable.
5. Install the 2230 solid-state drive or 2280 SSD in slot two, whichever applicable.
6. Install the base cover.
7. Follow the procedure in After working inside your computer.
Removing the system board (NVIDIA GeForce 3050 Ti)
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
3. Remove the memory.
4. Remove the
2230 solid-state drive or 2280 solid-state drive in slot one, whichever applicable.
5. Remove the 2230 solid state drive or 2280 solid-state drive in slot two, whichever applicable.
6. Remove the wireless card.
7. Remove the rear-I/O cover.
8. Remove the battery.
About this task
NOTE: This procedure only applies to computers shipped with a NVIDIA GeForce 3050 Ti graphics card.
The following image indicates the connectors on your system board.
54
To Next Page
