Next steps

1. Install the base cover.

2. Follow the procedure in After working inside your computer.

Wireless card

Removing the wireless card

Prerequisites

1. Follow the procedure in Before working inside your computer.

2. Remove the base cover.

About this task

The following image(s) indicate the location of the wireless card and provides a visual representation of the removal procedure.

Steps

1. Remove the screw (M1.6x1.8) that secures the wireless-card bracket to the wireless card and palm-rest and keyboard assembly.

2. Slide and remove the wireless-card bracket off the wireless card.

3. Disconnect the antenna cables from the wireless card.

4. Slide and remove the wireless card from the wireless-card slot.
