ALLEN & HEATH SQ-6 Reference Guide

 105
Reference Guide V1.5.0
Reset Mix Settings: Standard –
Processing type
Setting
48v
All off
Preamp gains
+28dB
HPFs
Out/100Hz
Gates
Out/-30dB
Inserts
Out
PEQs
In/Flat
GEQs
In/Flat
Compressors
Out/3:1/-9dB
Pans
Centred
Control
Setting
SoftKeys 1-6
Mute Groups 1 to 6
SoftKey 7
Unassigned
SoftKey 8
Global Tap Tempo
SoftKeys 9-16
Unassigned
SoftRotaries
Unassigned
Master Fader Mode
Mix Master
FX unit
Setting
1
EMT 250 reverb/FX1Snd/FX1Rtn
2
Hall 480 reverb/FX2Snd/FX2Rtn
3
Stereo Tap Vocal Delay/FX3Snd/FX3Rtn
4
ADT Classic/FX4Snd/FX4Rtn
5-8
Empty/Unpatched
Send type
Level
Input channels
-inf
FX return channels
0dB
Main LR master
0dB
Aux master
0dB
Group master
-inf
FX master
0dB
Routing
Setting
Input Stereo
40 mono (1-40), 4 stereo (ST1, ST2, ST3, USB)
Local Input patching
1-to-1 (as labelled), then unassigned to 46
Mix Bus Configuration
Aux 1-4 (mono), Aux 5-8 (stereo), Group 9-12 (Stereo)
LR Assign
All inputs and groups assigned
Aux assign and send
Inputs to all Aux, Pre-Fade, Post-EQ
Local Output patching (Aux)
1-to-1 for mono then sequential stereo
Local Output patching (Main)
11 (Main L) & 12 (Main R)
Local Output patching (Matrix 1)
A & B
AES output
Main LR
Remote Audio Unit Inputs
Unassigned
Remote Audio Unit Outputs
Unassigned
SQ to USB
Main LR on 1 & 2, then 1-to-1 direct out
USB to SQ
USB 1 & 2 to input channels 47 & 48

ALLEN & HEATH SQ-6 Specifications

General

Channels quantity	48 channels
Supported sample rates	96 kHz
Digital sound processing	- bit
DJ mixer	-
Product color	Black
Output impedance	75 Ω
MIDI out	Yes
RJ-45 ports quantity	1
Power consumption (typical)	- W

Weight and Dimensions

Depth	514.9 mm
Width	638 mm
Height	198 mm
Weight	14500 g
Package depth	680 mm
Package width	820 mm
Package height	360 mm
Package weight	17300 g
