ALLEN & HEATH SQ-6 Reference Guide

 106
Reference Guide V1.5.0
Reset Mix Settings: Monitor –
Processing type
Setting
48v
All off
Preamp gains
+28dB
HPFs
Out/100Hz
Gates
Out/-30dB
Inserts
Out
PEQs
In/Flat
GEQs
In/Flat
Compressors
Out/3:1/-9dB
Pans
Centred
Control
Setting
SoftKeys 1-8
Mute Groups 1 to 8
SoftKeys 9-16
Unassigned
SoftRotaries
Unassigned
Master Fader Mode
Listen Level
FX unit
Setting
1-4
EMT 250 reverb/FXSnd 1-4/FXRtn 1-4
5-8
Empty/Unpatched
Send type
Level
Input channels
0dB
FX return channels
0dB
Main LR master
0dB
Aux master
0dB
Group master
-inf
FX master
0dB
Routing
Setting
Input Stereo
48 mono (1-48)
Local Input patching
1-to-1 (as labelled), then unassigned to 48
Mix Bus Configuration
Aux 1-6 (mono), Aux 7-12 (stereo)
LR Assign
All inputs unassigned
Aux assign and send
Inputs to all Aux, Post-Fade, Post-Delay
Local Output patching (Aux)
1-to-1 for mono then sequential stereo
Local Output patching (Listen M)
12
Local Output patching (PAFL)
A & B
AES output
Main LR
Remote Audio Unit Inputs
Unassigned
Remote Audio Unit Outputs
Mixes 1-to-1, then Main LR on last 2 sockets.
SQ to USB
Unassigned
USB to SQ
Unassigned

ALLEN & HEATH SQ-6 Specifications

General

Channels quantity	48 channels
Supported sample rates	96 kHz
Digital sound processing	- bit
DJ mixer	-
Product color	Black
Output impedance	75 Ω
MIDI out	Yes
RJ-45 ports quantity	1
Power consumption (typical)	- W

Weight and Dimensions

Depth	514.9 mm
Width	638 mm
Height	198 mm
Weight	14500 g
Package depth	680 mm
Package width	820 mm
Package height	360 mm
Package weight	17300 g
