ALLEN & HEATH SQ-6 Reference Guide

 61
Reference Guide V1.5.0
Mix Filters –
Group
Filter
Includes
Patch
Mix Ext In source plus output patching of Group channels
Ext In Preamp
Preamp settings of Group Mix Ext In
Processing
All Group channel processing
Name/Colour
All Group channel names and colours
Fader
Master fader positions and output balance of Group channels
Pan/Balance
Master pan and balance positions for all Group channels
Mute
Master mute for all Group channels
Assigns to Group
All channel assignments to all groups
Aux
Filter
Includes
Patch
Mix Ext In source plus output patching of Aux channels
Ext In Preamp
Preamp settings of Aux Mix Ext In
Processing
All Aux channel processing
Name/Colour
All Aux channel names and colours
Fader
Master fader positions and output balance of Aux channels
Mute
Master mute for all Aux channels
Sends to Aux
All send levels to Aux channels
Main
Filter
Includes
Patch
Mix Ext In source plus output patching of the Main LR channel
Ext In Preamp
Preamp settings of Main LR Mix Ext In
Processing
Main LR channel processing
Name/Colour
Main LR channel name and colour
Fader
Master fader positions and output balance of the Main LR channel
Mute
Master mute for all Main LR channel
Matrix
Filter
Includes
Patch
Mix Ext In source plus output patching of Matrix channels
Ext In Preamp
Preamp settings of Matrix Mix Ext In
Processing
All Matrix channel processing
Name/Colour
All Matrix channel names and colours
Fader
Master fader positions and output balance of Matrix channels
Mute
Master mute for all Matrix channels
Sends to Matrix
All send levels to Matrix channels

ALLEN & HEATH SQ-6 Specifications

General

Channels quantity	48 channels
Supported sample rates	96 kHz
Digital sound processing	- bit
DJ mixer	-
Product color	Black
Output impedance	75 Ω
MIDI out	Yes
RJ-45 ports quantity	1
Power consumption (typical)	- W

Weight and Dimensions

Depth	514.9 mm
Width	638 mm
Height	198 mm
Weight	14500 g
Package depth	680 mm
Package width	820 mm
Package height	360 mm
Package weight	17300 g
