ALLEN & HEATH SQ-6 Reference Guide

 62
Reference Guide V1.5.0
Other Filters –
DCA/Mute Group
Filter
Includes
DCA Name/Colour
All DCA names and colours
Mute Group Name
All Mute Groups names
DCA Fader
All DCA fader values
DCA Mute
All DCA mutes
Mute Group Mute
All Mute Group mutes
DCA Assign
All DCA member assignments
Mute Group Assign
All Mute Group assignments
Input Sockets
Filter
Includes
Tie Line Only Preamps
Preamp parameters for connected sockets not assigned to a channel
Output Sockets
Filter
Includes
Local Patch
All patching to local output sockets (XLR, TRS and AES)
SLink Patch
All patching to the SLink port
USB Patch
All patching to USB (SQ-Drive and USB-B)
ME Patch
All patching to the ME system (SLink or I/O Port)
I/O Port Patch
All patching to the I/O Port
Control
Filter
Includes
SoftKeys
All SoftKey assignments
Strip Assign
Channel strip layout
Soft Rotaries
All Soft Rotary assignments
Ganging
All ganging assignments and linked parameters
Footswitches
Footswitch assignments
 It is common to block ‘SoftKeys’ and ’SoftRotaries’, so they continue to function in the
same way whenever scenes are recalled.
 Changes to Talkback and PAFL Ext In patching and preamp parameters are always
blocked as these are show level parameters.
 All output socket filters also affect socket settings e.g. AES sample rate setting.

ALLEN & HEATH SQ-6 Specifications

General

Channels quantity	48 channels
Supported sample rates	96 kHz
Digital sound processing	- bit
DJ mixer	-
Product color	Black
Output impedance	75 Ω
MIDI out	Yes
RJ-45 ports quantity	1
Power consumption (typical)	- W

Weight and Dimensions

Depth	514.9 mm
Width	638 mm
Height	198 mm
Weight	14500 g
Package depth	680 mm
Package width	820 mm
Package height	360 mm
Package weight	17300 g
