ALLEN & HEATH SQ-6 Reference Guide

 68
Reference Guide V1.5.0
Sync –
To push or pull data using the SQ-MixPad app, the SQ console must be in sync mode.
This avoids accidental overwriting of data on both the SQ console and SQ-MixPad.
To enter sync mode, go to the ‘Utility’ screen, then touch ‘Data’ followed by ‘Sync’.
Touch the ‘Sync Mode’ button then confirm you understand the implications of sync
mode in the pop-up to proceed.
Once in sync mode, pushing and pulling of data is controlled by SQ-MixPad.
 User permissions for the current user of both the console and SQ-MixPad must allow
‘Sync Push’ and/or ‘Sync Pull’ to transfer a show.
 Refer to SQ-MixPad help for more information on data transfer to and from MixPad.
 Starting sync mode will disconnect all devices aside from the one being connected to as
all network bandwidth is required without interruption.
sync mode

ALLEN & HEATH SQ-6 Specifications

General

Channels quantity	48 channels
Supported sample rates	96 kHz
Digital sound processing	- bit
DJ mixer	-
Product color	Black
Output impedance	75 Ω
MIDI out	Yes
RJ-45 ports quantity	1
Power consumption (typical)	- W

Weight and Dimensions

Depth	514.9 mm
Width	638 mm
Height	198 mm
Weight	14500 g
Package depth	680 mm
Package width	820 mm
Package height	360 mm
Package weight	17300 g
