Rockwell Automation Publication 1606-RM003A-EN-P - March 2019 19
DC-UPS with Integrated battery - 24V, 10 A
EMC
The unit is suitable for applications in industrial environment and in residential,
commercial, and light industry environment without any restrictions. CE mark is
in conformance with EMC guideline 89/336/EC and 93/68/EC and the low-
voltage Low Voltage Directive (LVD) 73/23/EC, 93/68/EC.
EMC Immunity According to Generic Standards EN 61000-6-1 and EN 61000-6-2 Criterion
Electrostatic discharge EN 61000-4-2 Contact discharge
Air discharge
8 kV
15 kV
Criterion A
(2)
Criterion A
(2)
(2) DIN rail earthed.
Electromagnetic RF field EN 61000-4-3 80 MHz-1 GHz 10V/m Criterion A
Fast transients (Burst) EN 61000-4-4 Input lines
Output lines
Signal lines
(1)
(1) Tested with coupling clamp.
2 kV
2 kV
2 kV
Criterion A
Criterion A
Criterion A
Surge voltage EN 61000-4-5 Output + ->-
Input + ->-
+ -> housing
500V
500V
500V
Criterion A
Criterion A
Criterion A
Conducted disturbance EN 61000-4-6 0.15…80 MHz 10V Criterion A
EMC Emission According to Generic Standards: EN 61000-6-3, EN 610000-6-4
Conducted emission EN 55022 input lines
EN 55022 output lines
Class B
(1)
Class B
(1)
(1) Informative measurement with voltage probe.
Radiated emission EN 55011, EN 55022 Class B
This device complies with FCC Part 15 rules. Operation is subjected to following two conditions: (1) this device cannot
cause harmful interference, and (2) this device must accept any interference received, including interference that can
cause undesired operation.
Switching Frequency
(1)
(1) The unit has three converters with three different switching frequencies included.
Description
Switching frequency of boost converter
Switching frequency of electronic output current limitation
Switching frequency of battery charger
100 kHz
78 kHz
19.5 kHz
Constant frequency
Constant frequency
Constant frequency
