20 Rockwell Automation Publication 1606-RM003A-EN-P - March 2019
DC-UPS with Integrated Battery - 24V, 10 A
Environment
Attribute Description
Operational temperature 0…40 °C (32…104 °F) Full output power
Storage temperature -20…+50 °C (-4…+122 °F) Storage and transportation
Relative humidity 5…95% IEC 60068-2-30
Do not energize while condensation is present.
Vibration sinusoidal
(1)
(1) Use wall mounting accessory for greater values.
2…17.8 Hz: ±1.6 mm (0.62 in.);
17.8…500 Hz: 1 g (0.03 oz)
IEC 60068-2-6
Shock 15 g (0.52 oz) 6 ms,
10 g (0.35 oz) 11 ms
IEC 60068-2-27
Altitude 0…6000 m (0…20,000 ft.) Approvals apply up to 2000 m (6560 ft).
Overvoltage category III EN 50178
II EN 50178, altitudes above 2000 (6560 ft)
Degree of pollution 2 EN 50178, non-conductive
Figure 22 - Nominal Mode - Output Current versus Ambient
Temperature
Figure 23 - Buffer Mode - Output Current versus Ambient
Temperature
