Rockwell Automation Publication 1734-UM013N-EN-P - September 2017 113
Chapter 6
Configure the Module for a SmartGuard
Controller
This chapter provides information about how to configure a SmartGuard™
controller and POINT Guard I/O™ modules by using USB (Universal Serial Bus)
connectivity. See the corresponding RSNetWorx™ for DeviceNet software help
files for network-configurator operating procedures.
Topic Page
Before You Begin 114
Set the Node Address 114
Auto-addressing with a 1734-PDN Adapter 116
Set Up Your DeviceNet Network 118
Configure the POINT Guard I/O Modules 119
Configure the SmartGuard Controller 128
Save and Download Module Configuration 133
For information about RSNetWorx for DeviceNet software, from the Help
menu, choose RSNetWorx Help.
