114 Rockwell Automation Publication 1734-UM013N-EN-P - September 2017
Chapter 6 Configure the Module for a SmartGuard Controller
Before You Begin
Confirm that you have these required items:
• RSNetWorx for DeviceNet software
• RSLinx® software, version 2.51 or later
• SmartGuard USB driver
The SmartGuard USB driver is already be in your RSLinx® software. If it is
not, load the driver onto your computer, and be aware of the folder
location as you browse to it later.
• 1734-PDN adapter
• SmartGuard controller and POINT Guard I/O module EDS files
Load the proper electronic data sheet (EDS) files by using the EDS Hardware
Installation Tool at http://www.rockwellautomation.com/resources/eds/
.
Include your 1752 SmartGuard controller and POINT Guard I/O modules.
Set the Node Address
Use RSNetWorx for DeviceNet software to set the node address of POINT
Guard I/O modules. The module has an out-of-box preset node address of 63.
We suggest that you connect and set the modules one at a time. Otherwise, the
address conflicts (all of them at 63) prevents communication with some of the
modules.
Cat. No. Required Version
1734-IB8S, 1734-OB8S 9 or later
1734-IE4S 10 or later
1734-OBV2S 21 or later
Cat. No. EDS File
1734-IB8S 00010023000F0100 (Series A)
00010023000F0200 (Series B)
1734-OB8S 0001002300100100 (Series A)
0001002300100200 (Series B)
1734-OBV2S 0001002300200100
1734-IE4S 0001002A00010100
The unique identifier for a safety node is a combination of the safety network
number (SNN) and node address. When the SNN is set, the current node
address is used to generate and store this identifier in nonvolatile memory.
Once the identifier is set, for safety reasons, the node address cannot be
changed unless specific action is taken to reset the POINT Guard I/O SSN of the
module. For this reason, you are required to set the node address before the
application of an SNN.
