Signal Attenuation with 10 Hz Input Filter
Signal Attenuation with 50 Hz Input Filter
0
-20
-40
-60
-80
-100
-120
-140
-160
-180
-200
0
2.62 Hz
Signal Frequency
-3 dB
10
20
30
40
50
60 Hz
Amplitude (in dB)
0
-20
-40
-60
-80
-100
-120
-140
-160
-180
-200
0 50 100 150 200 250 300 Hz
13.1 Hz
-3 dB
Amplitude (in dB)
Signal Frequency
