7-6 Troubleshooting
Starting Logical Group mismatch.
1-digit decimal value previously saved is
displayed (group 0, group 2, etc.).
Baud Rate mismatch.
Baud rate previously saved is displayed.
Abbreviated values are used.
Primary/Complementary Selection mismatch.
The mode previously saved is displayed.
Image Size mismatch.
Number of groups from 02 to 32 decimal
indicates previously saved selection.
Hold Last State (HLS) Selection mismatch. Yes or
no indicates if the HLS was (yes) or was not (no)
the previously saved selection.
Processor Restart Lockout (PRL) Selection
mismatch. Yes or no indicates if the PRL was
(yes) or was not (no) the previously saved
selection.
Link Response Selection mismatch.
Unrestricted (unr) or Restricted (rSd) indicates
previously saved selection.
Last Chassis/PLC-3 Backup mismatch.
or
or
or
or
or
or
to
or
or
or
or
