2 Preface
Related Documentation
The following documents contain additional information concerning
Allen-Bradley SLCt and PLC products. To obtain a copy, contact your
local Allen-Bradley office or distributor.
4 Configuration Contains DIP switch information, and shows odd
size chassis and image conditions.
5 Installation and
Wiring
Provides installation procedures and wiring
guidelines.
6 Start-up and
Operation
Explains powerup and initialization sequences,
normal operation, communication exceptions,
remote expansion power loss, invalid RIO link
transfers, and testing the 1747-ASB module.
7 Troubleshooting Shows how to interpret and correct problems
with your 1747-ASB module.
8 Application Examples Examines both SLC 500 and PLC-5/40t
applications using a 1747-ASB module. Gives
examples of the ladder programming necessary
to achieve the described result.
Appendix A Specifications Contains 1747-ASB and RIO link specifications,
as well as throughput information.
Appendix B Differences Between
the 1747-ASB and
1771-ASB Series C
Modules
Provides a point-by-point comparison of the 1747
and 1771 ASB modules.
Appendix C Worksheets Contains worksheets for setting the 1747-ASB
module's DIP switches and addressing remote
I/O modules with an SLC processor.
For Read This Document Document
Number
An overview of the SLC 500 family of products SLC 500 System Overview 1747-SO001
A description on how to install and use your Modular
SLC 500 programmable controller
Installation & Operation Manual for Modular
Hardware Style Programmable Controllers
User Manual
1747-UM011
Information regarding the use of a 1747-KE module as a
communications interface
DH-485/RS-232C Interface Module User
Manual
1747-6.12
Information regarding the use of the 1747-DCM as a remote
I/O device
Direct Communication Module User Manual 1747-6.8
