1 Publication 1747-UM006B-EN-P - June 2003
Appendix
C
DIP Switch and Address Configuration
Worksheets
This appendix provides worksheets for you to configure your DIP
switches and to address your I/O modules.
Use this worksheet to record the DIP switch settings for each of your
module.
DIP Switch Configuration
1
O
N
2456783
SW1
SW2
SW3
Logical Rack Number Bit 5 (MSB)
Logical Rack Number Bit 4
Logical Rack Number Bit 3
Logical Rack Number Bit 2
Logical Rack Number Bit 1
Logical Rack Number Bit 0 (LSB)
Logical Group Number Bit 1 (MSB)
Logical Group Number Bit 0 (LSB)
1
O
N
2456783
Baud Rate Bit 1 (MSB)
Baud Rate Bit 0 (LSB)
Primary/Complementary SLC Chassis
Reserved
ASB Module Image Size Bit 3 (MSB)
ASB Module Image Size Bit 2
ASB Module Image Size Bit 1
ASB Module Image Size Bit 0 (LSB)
1
O
N
2456783
Hold Last State
Processor Restart Lockout
Link Response
Last Chassis/PLC-3 Backup
Addressing Mode Bit 1 (MSB)
Addressing Mode Bit 0 (LSB)
Specialty I/O Mode
I/O Module Keying
SLC 500
CAT SER
SERIAL NO. FRN
R
U
L
SA
DIP Switches
1 2345678
SW1
O
N
1 2345678
SW2
O
N
1 2345678
SW3
O
N
IMPORTANT:
INSTALL IN SLOT ZERO OF MODULAR CHASSIS ONLY
REMOTE I/O ADAPTER MODULE
FAC 1M MADE IN USA
CURRENT REQUIREMENT: 375mA
LISTED IND. CONT. EQ.
FOR HAZ. LOC. A196
CLASS 1, GROUPS A, B, C AND D, DIV. 2
OPERATING
TEMPERATURE
CODE T3C
ON
OFF
Self Locking Tab
1747-ASB Module
R
