68 Rockwell Automation Publication 2080-UM004C-EN-E - March 2015
Appendix A Specifications
CJC error — ±1.2 °C @ 25 °C (77 °F)
Accuracy ±1.0 °C for TC and RTD @ 25 °C (77 °F)
Channels 2, non-isolated
RTD types supported 100 Ω Platinum 385
200 Ω Platinum 385
500 Ω Platinum 385
1000 Platinum 385
100 Ω Platinum 392
200 Ω Platinum 392,
500 Ω Platinum 392
1000 Ω Platinum 392
10 Ω Copper 427
120 Ω Nickel 672
604 Ω Nickel-Iron 518
—
Thermocouple types supported — J, K, N, T, E, R, S, B
Open circuit detection time 8…1212 ms 8…1515 ms
Power consumption 3.3 V, 40 mA
Temperature, surrounding air, max. 65 °C (149 °F)
Temperature, operating IEC60068-2-1 (Test Ad, Operating Cold),
IEC60068-2-2, (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
-20...65 °C (-4…149 °F)
Temperature, nonoperating IEC60068-2-1 (Test Ad, Operating Cold),
IEC60068-2-2, (Test Bd, Operating Dry Heat),
IEC 60068-2-14 (Test Nb, Operating Thermal Shock):
-40...85 °C (-40…185 °F)
North American temp code T4
Certifications – 2080-TC2, 2080-RTD2
Certification (when
product is marked)
(1)
(1) See the Product Certification link at http://www.rockwellautomation.com/products/certification/ for
Declarations of Conformity, Certificates, and other certification details.
Value
c-UL-us UL Listed Industrial Control Equipment, certified for US and Canada.
See UL File E322657.
UL Listed for Class I, Division 2 Group A,B,C,D Hazardous Locations,
certified for U.S. and Canada. See UL File E334470.
CE European Union 2004/108/EC EMC Directive, compliant with:
EN 61326-1; Meas./Control/Lab., Industrial Requirements
EN 61000-6-2; Industrial Immunity
EN 61000-6-4; Industrial Emissions
EN 61131-2; Programmable Controllers (Clause 8, Zone A & B)
C-Tick Australian Radiocommunications Act, compliant with:
AS/NZS CISPR 11; Industrial Emissions
General and Environmental Specifications – 2080-TC2, 2080-RTD2
Attribute 2080-RTD2 2080-TC2
