Rockwell Automation Publication 1756-RM012B-EN-P - April 2018 9
Chapter 1
Safety Integrity Level (SIL) Concept
SIL Certification
This section provides the SIL certifications and Performance Level for the
controllers.
TÜV Rheinland has approved GuardLogix 5580 and Compact GuardLogix
5380 controller systems for use in safety-related applications where the de-
energized state is considered to be the safe state.
All I/O examples in this manual are based on achieving de-energization as the
safe state for typical machine safety and Emergency Shutdown (ESD) systems.
Topic Page
SIL Certification 9
Proof Tests 10
GuardLogix Architecture 11
Controller Specifications 13
System Reaction Time 13
Contact Information If Device Failure Occurs 14
Controller System IEC 61508 IEC 62061 ISO 13849-1
Type-approved and
certified for use in
safety applications up
to and including:
Suitable for use in
safety applications up
to and including:
Suitable for use in safety
applications up to and including:
GuardLogix 5580
controller systems
SIL 2
(2)
SIL 3
(3)
(2) Primary controller that is used without a safety partner.
(3) Primary controller that is used with a safety partner.
SIL CL2
(2)
SIL CL3
(3)
Performance Level PLd (Cat. 3)
(2)
Performance Level PLe (Cat. 4)
(3)
Compact GuardLogix 5380
SIL 2 controller systems
(1)
(1) Compact GuardLogix 5380 controller catalog numbers with a ‘2’ at the end, for example, 5069-L3xxxxxS2, are for use in safety
applications up to and including SIL 2.
SIL 2 SIL CL2 Performance Level PLd (Cat. 3)
IMPORTANT In the remainder of this publication:
• SIL 2 represents SIL 2, SIL CL2, and PLd
• SIL 3 represents SIL 3, SIL CL3, and PLe
