92 Rockwell Automation Publication 1756-RM012B-EN-P - April 2018
Appendix D Checklists for GuardLogix Safety Applications
Checklist for Safety Outputs
For programming or startup, an individual requirement checklist must be
completed for every safety output in the system. This method is the only way
to make sure that the requirements are fully and clearly implemented. This
checklist can also be used as documentation on the connection of external
wiring to the application program.
Output Checklist for GuardLogix System
Company
Site
Safety Function Definition
SIL Output Channels
Number Output Device Requirements
Fulfilled
CommentYes No
1 Have you followed installation instructions and precautions to conform to applicable safety standards?
2 Have you performed project validation tests on the devices?
3 Have you uploaded and compared the configuration of each device to the configuration sent by configuration
tool?
4 Have you verified that test outputs are not used as safety outputs?
5 Are devices wired in compliance with the target standard and required safety level?
6 Have you verified that the electrical specifications of the output and the actuator are compatible?
To Next Page
