Rockwell Automation Publication 2071-IN001F-EN-P - February 2017 13
Kinetix 3 Component Servo Drives
Connectors and Cables
Connector Type of Connector Wire Size Cat. No.
Input Power
Single-row, spring clamp
connectors spaced 7.5 mm
(0.30 in.)
2.5…0.08 mm
2
(12…28 AWG)
8 mm (0.31 in.) of wire
that is exposed
2071-CONN1
(1)
(1) The tool (Wago 231-131) for opening individual cage-clamp power connectors is supplied with the drive. You can purchase the replacement tool
separately.
Output (Motor) Power
Input/output 50-pin mini-D
0.25…0.05 mm
2
(24…30 AWG)
2071-TBIO
Motor Feedback 20-pin mini-D 2071-TBMF
Connector Type of Mating Cable Cable
Serial Interface
Comm0A, Comm0B
Configuration
2090-CCMPCDS-23AA01
2090-CCMPCDS-23AA03
Control
2090-CCMCRDS-48AA01
2090-CCMCRDS-48AA03
Drive to drive control
2090-CCMDSDS-48AA01
2090-CCMDSDS-48AAP3
Drive to 1203-USB converter
(1)
(1) For use with Kinetic lication3 drives series B and later.
2090-CCMUSDS-48AA01
2090-CCMUSDS-48AA03
