18 Rockwell Automation Publication 2071-IN001F-EN-P - February 2017
Kinetix 3 Component Servo Drives
Fuse/Contactor Specifications
The Kinetix 3 drives use internal solid-state motor short-circuit protection and, when protected
by suitable branch circuit protection, are rated for use on a circuit capable of delivering up to
100,000 A. Fuses or circuit breakers, with adequate withstand and interrupt ratings, as defined in
NEC or applicable local codes, are permitted.
The following fuse examples are recommended for use with Kinetix 3 drives.
Fuse and Contactor Specifications
Drive Cat. No.
AC Input Power
(1)
(2)
(3)
Recommended Fuse
(1) Fuses that are specified are Bussmann fuses.
(2) FNQ-R fuses are described as time-delay fuses, Class CC.
(3) LPJ fuses are described as dual-element time-delay fuses, Class J.
Control Power
(2)
(4)
Recommended Fuse
(4) FRS-R fuses are described as dual-element time-delay fuses, Class RK5.
Contactor
(5)
(5) For contactors: x represents coil voltage, y represents the number of contacts.
2071-AP0
FNQ-R-7
FRS-R-2-1/2
FNQ-R-7-1/2
LPJ-6
100-K05xy
2071-AP1
2071-AP2 100-K09xy
2071-AP2 FNQ -R-10 100-K12xy
2071-AP8
FNQ-R-20
LPJ-20
100-C16xy
2071-A10
2071- A15
FNQ-R-30
LPJ-30
100-C23xy
