374 Rockwell Automation Publication 2198-UM002G-EN-P - February 2019

Appendix A Interconnect Diagrams

Figure 200 - Regenerative Bus Supply Block Diagram

(1) Ground screw in the installed (default) configuration.

CONV OK–

CONV OK+

CONT EN–

CONT EN+

24V+

24V–

24V DC

–

DC–

DC+

DC–

Three-phase

Input Power

(IDP) Connector

24V Control Power

(CP) Connector

Ground Screw

(1)

Control

Chassis

Contactor Enable

(CED) Connector

DC Bus Power

(DC) Connector

Active Shunt

(RC) Connector
