Rockwell Automation Publication 2198-UM002G-EN-P - February 2019 383
Upgrade the Drive Firmware Appendix B
Configure Logix 5000 Controller Communication
This procedure assumes that your communication method to the Logix 5000
controller is the Ethernet network. It also assumes that your Ethernet
communication module or Logix 5000 controller has already been configured.
For more controller information, refer to Additional Resources
on page 13.
Follow these steps to configure Logix 5000 controller communication.
1. Open your RSLinx Classic software.
2. From the Communications menu, choose Configure Drivers.
The Configure Drivers dialog box appears.
3. From the Available Driver Types pull-down menu, choose Ethernet
devices.
4. Click Add New.
The Add New RSLinx Classic Driver dialog box appears.
5. Type the new driver name.
6. Click OK.
The Configure driver dialog box appears.
